Titanium clad aluminum as rod material in desired length, max. rod length 3 m.Titanium sheath approx. 0.8 mm, material: 3.7025 grade 2Optionally open sawn edges or tightly welded on both sides. Alternatively, matching cover plates can be ordered separately for self-tight welding.Available dimensions: 20x10 mm or other dimensions on request.
Titanium clad aluminum as rod material in desired length, max. rod length 3 m.Titanium sheath approx. 0.8 mm, material: 3.7025 grade 2Optionally open sawn edges or tightly welded on both sides. Alternatively, matching cover plates can be ordered separately for self-tight welding.Available dimensions: D=19 mm, D=20 mm or other dimensions on request.
Titanium clad aluminum as rod material in desired length, max. rod length 3 m.Titanium sheath approx. 0.8 mm, material: 3.7025 grade 2Optionally open sawn edges or tightly welded on both sides. Alternatively, matching cover plates for self-tight welding can be ordered separately.Available dimensions: 20x20 mm or other dimensions on request.
Titanium clad copper as rod material in the desired length, max. rod length 3 m.Titanium sheath approx. 0.8 mm, material: 3.7025 grade 2 Optionally open sawn edges or tightly welded on both sides. Alternatively, matching cover plates can be ordered separately for self-tight welding.Available dimensions: 20x10 mm, 25x13 mm or other dimensions on request.
Titanium clad copper as rod material in the desired length, max. rod length 3 m.Titanium sheath approx. 0.8 mm, material: 3.7025 grade 2Optionally open sawn edges or tightly welded on both sides. Alternatively, matching cover plates for self-tight welding can be ordered separately.Available dimensions: D=10 mm or other dimensions on request.
Titanium clad copper as rod material in the desired length, max. rod length 3 m.Titanium sheath approx. 0.8 mm, material: 3.7025 grade 2Optionally open sawn edges or tightly welded on both sides. Alternatively, matching cover plates can be ordered separately for self-tight welding.Available dimensions: 10x10 mm, 13x13 mm, 15x15 mm or other dimensions on request.
Titanium hexagon head screw, material 3.7035 grade 2, DIN 912.Size selectable: M5, M6, M8, M10Length selectable: 10mm, 20mm, 25mm, 30mm, 40mm, 50 mmOther sizes or special screws on request
Titanium flat material, material: 3.7025 Grade 2 in desired length, max. rod length 3 m.Available dimensions: 13x6.5 mm, 19x6.5 mm, 20x10 mm, 25x6.5 mm, 25x13 mm, 30x6 mm, 40x8 mm, 50x13 mm, 50x20 mm, 60x25 mm
Titanium hexagon head screw, material 3.7035 Grade 2, DIN 933.Rolled threads for longer service life in anodizing processes. The compacted surface results in less seized threads.Available sizes: M3, M4, M5, M6, M8, M10, M12, M14, M16, M18, M20Length selectable: 10mm, 12mm, 16mm, 20mm, 25mm, 30mm, 35mm, 40mm, 50mm, 60mm, 80mm, 90mm, 100mmOther sizes or special screws on request.
Titanium round material, material: 3.7025 Grade 2 bright in desired length, max. rod length 3 m.Available dimensions: D=6 mm, D=8 mm, D=10 mm, D=12 mm, D=15 mm, D=16 mm, D=18 mm,
D=19 mm, D=20 mm, D=22 mm, D=25 mm, D=30 mm, D=35 mm, D=40 mm, D=50 mm, D=60 mm, D=70 mm
We supply titanium clad copper in various dimensions. This material consists of a copper core with an approx. 0.8 mm thick, tightly rolled titanium sheath. This provides the chemical and physical resistance of titanium with the conductivity of copper. Titanium has a conductivity of 0.6 A/sqm, whereas copper has 4 A/sqm, making this material suitable for all applications (e.g. frames for hard anodizing) where high conductivity is required. With titanium-coated copper, a much lighter and slimmer frame construction can be selected with significantly better conductivity. The so-called TICU is available as bar material and must be tightly welded with small cover plates at the cut edges. Comparable material in the form of titanium-coated aluminum is also available.
